terNario Navigator HiFi NAS Router

Hardware Architecture

1. Core Power: The Ultimate Computing Heart for Superior Performance
Equipped with a flagship-grade RK3568 core board, featuring 4GB of RAM (16 times that of conventional routers) and 32GB of onboard eMMC storage (32 times the capacity), this powerhouse delivers exceptional computing performance for high-bitrate audio streaming and multitasking. Designed specifically for the most demanding audiophile scenarios.

2. Signal Purity Engineering: A Revolutionary Design Philosophy
With a self-developed 8-layer PCB expansion board, breaking the limitations of traditional 4-layer designs, this innovation introduces a unique digital/analog signal isolation technology. Sensitive high-speed signals and analog circuits run on separate paths, minimizing electromagnetic interference to an extreme degree, creating a data transmission environment as pure as a vacuum.

3. Dual Optical Fiber Network Channels: The Backbone of Future Data Transmission
Built on the RK3568 dual-network stack, featuring dual SFP fiber optic interfaces optimized for xPON modules, this system supports dual-input fiber broadband direct dialing and is compatible with all mainstream SFP devices. It forms a near-zero jitter network transmission bridge, ensuring every bit of data remains pristine and accurate.

4. Peak-Speed Data Channels: A Direct-Link Architecture for Unparalleled Performance
By leveraging the RK3568 PCIe 3.0 channel and a 2.5G network chip, this system bypasses the limitations of traditional bridge-mode networking, providing millisecond-level response times for dual-network concurrent operations and high-capacity NAS read/write tasks. Whether instantaneously accessing a vast lossless music library for hundreds of users or synchronizing 4K audio-video streams across multiple devices, it handles all scenarios with ease.

5. Reference-Grade Clock System: Precision Beyond Industry Standards
Combining a 25MHz AT-cut VCOCXO temperature-controlled crystal oscillator with a military-grade PLL solution, this system achieves an ultra-low phase noise reference clock of 1Hz/-82dBc. When paired with the terNario Greenwich 10M master clock for phase locking, phase noise further improves to 1Hz/-105dBc*—7dB superior to top-tier SC-cut OCXOs. Additionally, it completely eliminates high-frequency attenuation issues commonly found in DDS solutions, delivering atomic-clock-level precision timing for the network chip and PCIe bus.

6. Revolutionary Linear Power Supply: Redefining the Purity of Energy
A meticulously engineered EMI filter circuit—featuring WIMA and RIFA safety capacitors alongside WE 10A common-mode inductors—ensures ultra-clean power input. Dual 25W Talema toroidal transformers, combined with a Nichicon Gold Audio capacitor array providing 38,000μF of energy storage, work alongside an ON Semiconductor 8A rectifier module and 11 independent LDO voltage regulators. With no switching power supplies in the entire power chain, the system achieves an ultra-low power ripple of just 0.5μV* (equivalent to enterprise-grade storage backplanes), delivering laboratory-grade power purity for every chip and hard drive.

7. Storage Expansion Mastery: Minimalist Design, Maximum Capacity
Native dual SATA 3.0 interfaces support up to 16TB of solid-state storage (2×8TB SSDs), while a high-speed USB 3.0 port enables additional storage expansion. With independent LDO power regulation and a physically isolated backplane, data transmission remains as fluid and dynamic as a symphony.

8. Industrial Aesthetic Excellence: The Fusion of 6061 Aluminum and Precision Engineering
A 25kg solid aerospace-grade aluminum billet, meticulously CNC-milled over 72 hours, forms a seamless, screw-free chassis with a dual-layer isolation structure. The integration of thermal management and electromagnetic shielding ensures that this precision audio instrument is as much a work of modern art as it is a technological marvel.
