terNario Dialogos PRO MAX – Dedicated Audio Network Hub

Revolutionary Network Purification Architecture

Built upon the flagship Marvell 88E1112 chipset, the multi-layered signal isolation matrix introduces an innovative 3+1 multi-protocol transmission channel layout. The specially designed Isolated RJ45 port, featuring military-grade circuit isolation technology, works in synergy with a customizable SFP optical communication link, forming a multi-tier noise-reduction barrier during digital signal transmission. The pioneering Dual-Domain Fiber Interconnect Technology completely separates the core music streamer from conventional network equipment, eliminating EMI pollution at the physical layer to preserve audio signal purity.

Phase Noise Termination System

The system adopts a groundbreaking 25MHz AT-cut VCOCXO crystal oscillator with an ultra-low phase noise of -85dBc@1Hz, combined with a triple PLL phase-locking system that achieves an absolute time reference with an error margin of just ±0.001ppm. When paired with the Greenwich 10MHz reference clock, the phase noise control reaches an astonishing -105dBc@1Hz—outperforming top-tier SC-cut OCXOs by 7dB. This ensures near-zero deviation, delivering precise clock reconstruction across the entire frequency spectrum, completely eliminating the phase distortion typically caused by traditional DDS clock synthesis.

Ultimate Power Platform

An uncompromisingly engineered hybrid linear power system, featuring dual Talema toroidal transformers, is further refined through a proprietary WE common-mode inductor electromagnetic trap and an RIFA/WIMA film capacitor array. Complemented by a fully discrete dual-stage LDO regulation system, each output port delivers a steady 1.5A of current. The exclusive 40,000μF audiophile-grade electrolytic capacitor matrix drives system ripple noise down to an unprecedented 4μV level.

Chip-Level Power Topology

A revolutionary 19-channel ultra-low-noise power distribution array, with each LDO regulator module forming a nano-scale energy transfer network. Utilizing a TI ultra-low-noise power solution, it achieves an industry-leading ripple suppression rating of ±0.5μV (as per TI’s official tests). The star topology architecture ensures that every core chip benefits from an optimal power supply radius, creating a self-purifying energy ecosystem within a compact 3.5cm² space, keeping all power nodes in a state of near-zero self-excited oscillation—setting an entirely new benchmark for network power purity.

An Acoustic Engineering Marvel

The chassis is precision-milled from solid 6061 aluminum alloy over 72 hours of CNC machining, achieving a perfectly balanced structure. Anodized surface treatment and a scientifically optimized heat dissipation framework create an optimal balance between thermodynamics and electromagnetic shielding. The floating mainboard installation and screwless minimalist aesthetic seamlessly integrate audiometric-grade precision with modern industrial design philosophy.

Key Specifications

• Phase Noise: -85dBc@1Hz (typical) / -105dBc@1Hz (with TerNario Greenwich 10M clock lock)
• EMI Isolation: >95dB@100MHz
• Primary Linear Power Ripple: 4μV (typical)
• Signal Jitter: <82fs RMS (10Hz-1MHz)

Audiophile System Integration Recommendations

• Connect Isolated RJ45 ports to noisy network sources such as modems/routers.
• Directly link LAN1-3 ports to core music streaming components.
• The SFP port can optionally be used for long-distance network nodes.
• Allow 200 hours of component burn-in for optimal sound performance.
• Maintain continuous power-on operation for best results.
• When LED indicators transition from amber to pure ice-green, the nano-scale digital symphony hall is fully prepared for flawless music reproduction.
